HDCU-3300 Camera Control Unit for HDC-3300 SuperMotion HD camera

HDCU-3300 Camera Control Unit for HDC-3300 SuperMotion HD camera

OUR PRICE:
£25,000.00 ex. Vat
£30,000.00 inc. Vat

This is a secondhand item

Request more information

  More information

  A telephone callback

  An official quotation

  An on-site demonstration

CAPTCHA Image

HDCU-3300 Camera Control Unit for HDC-3300 SuperMotion HD camera Description

High Definition production has now entered into the mainstream. Viewers naturally expect all of the production features they have become used to in the SD world. Sony have responded to this challenge with a superb new slow-motion system, the HDC-3300 camera and HDCU-3300. The first system in the world to achieve three times image capture, for really slow and smooth replay.

The HDCU-3300 is dedicated to working with the HDC-3300 camera. It connects via a high speed version of the SMPTE Hybrid Optical Fibre. The transmission format is digital so there is no discernable degradation with fibre connections up to 2500m in length. The camera captures full HD resolution images (1920 x 1080), at three times the frame rate of the common production standards. In addition to the normal camera control function, the CCU processes the incoming image data and re-formats it onto 3 HD-SDI outputs for direct connection to the playback server.

The CCU also outputs a real-time HD signal from the camera for maximum operational flexibility.


HDCU-3300 Camera Control Unit for HDC-3300 SuperMotion HD camera Specification

  • HDCU-3300R HD Camera Control Unit
  • HKCU-1005 (SDI OUT PUT EXPANSION UNIT)

Enhanced range of output signals

The HDCU-3300 provides up to 8 SDI outputs, 4 of which are assignable (in pairs) as either HD or SD. A high performance downconvertor is included, to deliver the SD signals, and aspect ratio conversion can be carried out if required. Character display and other system information can be superimposed on 2 of the outputs for monitoring purposes. A downconverted VBS (composite analogue) output is also available for picture monitoring.

Expandable Outputs
2 Expansion slots are available for additional output interface cards (common to HDCU-1000 and 1500), if additional outputs or signal formats are required.

TCP-IP control interface
In addition to standard 700
series control I/F, the HDCU-3300 includes an Ethernet interface, offering alternative control system architecture.
